The new competitively priced semi automatic single gouge CNC wood lathe suitable for producing a range of turned components.
The CNC control means that no sample or template is needed making it very simple and quick to set up and so ideal for short production runs and one of's. As standard the machine has a 15" colour touch screen and OSAI controller featuring CT CAD software to easily create the profile to be turned.
There is also the possibility to install the CT CAD software on remote PC or laptop and transfer the data to the machine controller via USB stick. Features of the software include the possibility to program up to 10 working passes, multi cuts on specific parts of the turning or return cuts. As the X and Y axis (traverse speed / depth of cut) are NC controlled it is possible to achieve excellent quality and definition of the turned component in all types of materials. The machine is also equipped with 2 x mechanically operated dowel / tenon knives.

Centauro TSTAR CNC  PDF BROUCHURE

Technical Specification:
Max. distance between centres mm 1600 / 2000
Height of centres over bed mm 250
Max. turning ¥ (manual turning) mm 500 (350)
Max turning and milling diameter mm 240 (170)
Max ¥ permitted by traveling steady mm 90 (65) standard
110 (80) optional
Connection for driving and tailstock centre 3 C.M.
Spindle speed R.P.M. . 650,900,1100,1300,1500,1800,2200,3000
X-Y axis speed Mt/min 12 / 6
Spindle motor power HP 3 - 4 (2,2 - 3 KW)
Installed power 5,67 Kw
Net weight 800 Kg
Optional Equipment
Barley twist & fluting attachment
Cobalt gouge 0.6 or 1.25mm radius
Tantung gouge 0.6 or 1.25mm radius
Reinforced ballbearing ctre 48mm
Additional dia steady bushes
AG125 beanch mounted tool grinder with diamond wheel
